Specifications:
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 – 95% (non-condensing) |
| Min Storage Temperature | -13 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 10 – 95% (non-condensing) |
| Header | |
| Compatibility | PC |
| Manufacturer | Cisco Systems |
| Packaged Quantity | 1 |
| Product Line | Cisco Catalyst |
| Model | 2960X-24TS-L |
| Brand | Cisco |
| Interface Provided | |
| Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Qty | 4 |
| Type | USB |
| Connector Type | Type A |
| Comments | Management |
| Miscellaneous | |
| Compliant Standards | AS/NZS 60950-1, AS/NZS CISPR22:2004 Class A,
CISPR 22 Class A, CISPR 24, CNS 13438(95) Class A, CSA C22.2 No. 60950-1 Second Edition, Directive 2011/65/EU, EN 300386, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC CFR47 Part 15, ICES-003 Class A, IEC 60950-1 Second Edition, KN22 Class A, KN24, RoHS, UL 60950-1 Second Edition, VCCI Class A |
| Authentication Method | Kerberos, RADIUS, Secure Shell (SSH), TACACS |
| MTBF | 564,910 hours |
| Height (Rack Units) | 1 |
| Networking | |
| Type | Switch |
| Remote Management Protocol | CLI, HTTP, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet, TFTP |
| Compliant Standards | IEEE 802.1ae, IEEE 802.1AX, IEEE 802.1D,
IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Status Indicators | Link/activity, Port duplex mode, Port transmission speed, Status, System |
| Ports Qty | 24 |
| Features | Access Control List (ACL) support, ARP support,
Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Cisco EnergyWise technology, DHCP support, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support,Energy Efficient Ethernet, Hot Standby Router Protocol (HSRP) support, IPv4 support, IPv6 support, Jumbo Frames support, Layer 2 switching, Link Aggregation Control Protocol (LACP), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, NetFlow, Port Aggregation Protocol (PAgP) support, RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST ), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Trivial File Transfer Protocol (TFTP) support, Trunking, Uni-Directional Link Detection (UDLD), Unicast Reverse Path Forwarding (URPF), VLAN support |
| Max Units In A Stack | 8 |
| Subcategory | Network hubs and switches |
| Manageable | Yes |
| Form Factor | Desktop, Rack-mountable |
| Jumbo Frame Support | 9216 bytes |
| Subtype | Gigabit Ethernet |
| Power Device | |
| Frequency Required | 50/60 Hz |
| Nominal Voltage | AC 120/230 V |
| Features | Redundant Power System (RPS) connector |
| Power Redundancy | Optional |
| Type | Internal power supply |
| Processor | |
| Type | APM86392 |
| Clock Speed | 600 MHz |
| Service | |
| Support Details Type | Technical support |
| Support Details Service Included | Consulting |
| Slot Provided | |
| Type | Stacking Module slot |
| Total Qty | 1 |
| Free Qty | 1 |
| Software | |
| Type | Cisco IOS LAN Base |
| Dimensions & Weight | |
| Width | 17.5 in |
| Depth | 11 in |
| Height | 1.8 in |
| Weight | 8.82 lbs |
| Capacity | |
| Type | Virtual interfaces (VLANs) |
| Value | 1023 |
| Flash Memory | |
| Installed Size | 128 MB |
| Performance | |
| Type | Switching capacity |
| Value | 216 Gbps |
| Ports | |
| Qty | 24 |
| Type | 10/100/1000 |
| Ports (2nd) | |
| Qty | 4 |
| Type | Gigabit SFP |
| RAM | |
| Installed Size | 512 MB |
